Forklift EP EFL 203B
| Manufacturer | EP |
| Model designation | EFL203 |
| Drive | Electric |
| Operator type | Seated |
| Load capacity | 2000kg |
| Load center distance | 500mm |
| Load distance centre of drive axle to fork | 495mm |
| Wheelbase | 1540mm |
| Service weight | 3540kg |
| Axle loading laden front/rear | 4930/610kg |
| Axle loading unladen front/rear | 1640/1900kg |
| Tyre type | Pneumatic |
| Tyre size front | 7.00-12-12PR |
| Tyre size rear | 18x7-8-14PR |
| Wheels number front/rear | 2x/2 |
| Tread width front | 975mm |
| Tread width rear | 955mm |
| Tilt of mast/fork carriage forward/backward | 6/6 |
| Retracted mast height | 2090mm |
| Free lift | 120mm |
| Lift height | 3000mm |
| Height mast extended | 4025mm |
| Height of overhead guard | 2165mm |
| Seat height/standing height | 1095mm |
| Tow coupling height | 310mm |
| Overall height | 3426mm |
| Length to face of forks | 2356mm |
| Overall width | 1154mm |
| Fork dimensions | 40x122x1070 |
| A,B Fork carriage | class/type A,B 2A |
| Fork carriage width | 1040mm |
| Ground clearance laden, below mast | 125mm |
| Ground clearance center of wheelbase | 150mm |
| Aisle width for pallets 1000x1200 crossways | 3805mm |
| Aisle width for pallets 800x1200 lengthways | 4005mm |
| Turning radius | 2110mm |
| Travel speed laden/unladen | 14/15km/h |
| Lifting speed laden/unladen | 0.29/0.36m/s |
| Lowering speed laden/unladen | 0.43/0.11m/s |
| Max gradeability laden/unladen | 15/20% |
| Service brake | Hydraulic |
| Parking brake | Mechanical |
| Drive motor rating S2 60min | 10kW |
| Lift motor rating S3 15% | 16kW |
| Battery voltage/nominal capacity | 80V230AH |
| Type of drive control | AC |
| Steering design | Hydraulic |
| Sound pressure level at the driver's ear | 74dB(A) |
In stock
£5,460.00
Excl. Tax:
£4,550.00
Excl. Tax:
Description / Forklift EP EFL 203B
| Manufacturer | EP |
| Model designation | EFL203 |
| Drive | Electric |
| Operator type | Seated |
| Load capacity | 2000kg |
| Load center distance | 500mm |
| Load distance centre of drive axle to fork | 495mm |
| Wheelbase | 1540mm |
| Service weight | 3540kg |
| Axle loading laden front/rear | 4930/610kg |
| Axle loading unladen front/rear | 1640/1900kg |
| Tyre type | Pneumatic |
| Tyre size front | 7.00-12-12PR |
| Tyre size rear | 18x7-8-14PR |
| Wheels number front/rear | 2x/2 |
| Tread width front | 975mm |
| Tread width rear | 955mm |
| Tilt of mast/fork carriage forward/backward | 6/6 |
| Retracted mast height | 2090mm |
| Free lift | 120mm |
| Lift height | 3000mm |
| Height mast extended | 4025mm |
| Height of overhead guard | 2165mm |
| Seat height/standing height | 1095mm |
| Tow coupling height | 310mm |
| Overall height | 3426mm |
| Length to face of forks | 2356mm |
| Overall width | 1154mm |
| Fork dimensions | 40x122x1070 |
| A,B Fork carriage | class/type A,B 2A |
| Fork carriage width | 1040mm |
| Ground clearance laden, below mast | 125mm |
| Ground clearance center of wheelbase | 150mm |
| Aisle width for pallets 1000x1200 crossways | 3805mm |
| Aisle width for pallets 800x1200 lengthways | 4005mm |
| Turning radius | 2110mm |
| Travel speed laden/unladen | 14/15km/h |
| Lifting speed laden/unladen | 0.29/0.36m/s |
| Lowering speed laden/unladen | 0.43/0.11m/s |
| Max gradeability laden/unladen | 15/20% |
| Service brake | Hydraulic |
| Parking brake | Mechanical |
| Drive motor rating S2 60min | 10kW |
| Lift motor rating S3 15% | 16kW |
| Battery voltage/nominal capacity | 80V230AH |
| Type of drive control | AC |
| Steering design | Hydraulic |
| Sound pressure level at the driver's ear | 74dB(A) |
