CPD TVL 1500/1800/2000 kg

Manufacturer                   EP
Model designation                            CPD15TVL
Drive                                                       Electric
Operator type                                     Seated
Load capacity                                     1500kg
Load center distance                       500mm
Load distance center of drive axle to fork             420mm
Wheelbase                                            1230mm
Service weight                                      2950kg
Axle loading laden front/rear         3928/522kg
Axle loading unladen front/rear    1305/1645kg
Tyre type                                                  Solid
Tyre size front                                        18x7-B
Tyre size rear                                          15x4 5-8
Wheels number front/rear               2x/2mm
Tread width front                                  943mm
Thread width rear                                 175mm
Tilt of mast/fork carriage forward/backward         6/6
Retracted mast height                       2075mm
Free lift                                                      100mm
Lift height                                                 3000mm
Height mast extended                        4055mm
Height of overhead guard (cabin)    2078mm
Seat height/standing height              1050mm
Tow coupling height                              600mm
Overall length                                     2733mm
Length of face of forks                        1813mm
Overall width                                            1070mm
Fork dimensions                               100 x 40 x 920mm
A,B Fork carriage  class/type A,B     2A
Fork carriage width                                1040mm
Ground clearance laden below mast                        89mm
Ground clearance center of wheelbase                   92mm
Aisle width for pallets 1000x1200 crossways           3175mm
Aisle width for pallets 800 x 1200 lengthways         3300mm
Turning radius                                          1450mm
Travel speed laden/unladen               13/14km/h
Lifting speed laden/unladen               0.33/0.5 m/s
Lowering speed laden/unladen          0.55/0.55m/s
Max gradeability laden/unladen        10/15%
Service brake                                              Hydraulic
Parking brake                                             Mechanical
Drive motor rating S2 60min                 5.0X2 kW
Lift motor rating S3 15%                          11 kW
Battery voltage/nominal capacity       80V/150AH V/ah
Battery weight                                              220kg
Type of drive control                                   AC
Steering design                                            Hydraulic
Sound pressure level at the drivers ear                          68dB(A)

In stock

Customizable Options:

  £5,140.08
Excl. Tax: £4,283.40

Description / CPD TVL 1500/1800/2000 kg

Manufacturer                   EP
Model designation                            CPD15TVL
Drive                                                       Electric
Operator type                                     Seated
Load capacity                                     1500kg
Load center distance                       500mm
Load distance center of drive axle to fork             420mm
Wheelbase                                            1230mm
Service weight                                      2950kg
Axle loading laden front/rear         3928/522kg
Axle loading unladen front/rear    1305/1645kg
Tyre type                                                  Solid
Tyre size front                                        18x7-B
Tyre size rear                                          15x4 5-8
Wheels number front/rear               2x/2mm
Tread width front                                  943mm
Thread width rear                                 175mm
Tilt of mast/fork carriage forward/backward         6/6
Retracted mast height                       2075mm
Free lift                                                      100mm
Lift height                                                 3000mm
Height mast extended                        4055mm
Height of overhead guard (cabin)    2078mm
Seat height/standing height              1050mm
Tow coupling height                              600mm
Overall length                                     2733mm
Length of face of forks                        1813mm
Overall width                                            1070mm
Fork dimensions                               100 x 40 x 920mm
A,B Fork carriage  class/type A,B     2A
Fork carriage width                                1040mm
Ground clearance laden below mast                        89mm
Ground clearance center of wheelbase                   92mm
Aisle width for pallets 1000x1200 crossways           3175mm
Aisle width for pallets 800 x 1200 lengthways         3300mm
Turning radius                                          1450mm
Travel speed laden/unladen               13/14km/h
Lifting speed laden/unladen               0.33/0.5 m/s
Lowering speed laden/unladen          0.55/0.55m/s
Max gradeability laden/unladen        10/15%
Service brake                                              Hydraulic
Parking brake                                             Mechanical
Drive motor rating S2 60min                 5.0X2 kW
Lift motor rating S3 15%                          11 kW
Battery voltage/nominal capacity       80V/150AH V/ah
Battery weight                                              220kg
Type of drive control                                   AC
Steering design                                            Hydraulic
Sound pressure level at the drivers ear                          68dB(A)
